Features
– Large color LCD display, Touch screen, In-built 10 incubators & 3 timers
– Flow-cell and Cuvette test mode compatible
– 7 standard filters, 90 test items pre-programmed
– Real time curve showing, Reagent open system
– Reagent and Sample blank, Memory for reagent blank
– Use-friendly operation software
– Lamp saving, self- check and auto result-storing functions
– Up to 10,000 sample results can be stored
– Internal printer, data communication available by RS-232 serial port connected to P.C.
– Two forms in result output available by external printer connected with P.C., including
patient comprehensive report
Technical Specification
Analytical Modes: Kinetic, End point, Two point, Absorbance
Light Source: Halogen lamp, 6V/10W
Measurement Range: 0-4.500 Abs
Measurement Precision: 0.001Abs(display), 0.0001Abs(calculation)
Wavelength: 340,405,492,510,546,578,630nm, 1 more filter optional
Wavelength Precision: ±2nm (Width ≤ 10nm)
Carry Over: < 1%
Quality Control Curve: X 、SD、CV%、L-J quality control curve for every test item
Sample Volume: 0-3000ul (≥500uL recommended)
Temperature Control: 37°C, 30°C, 25°C ±1°C by Peltier, In-built 10 incubators:37±0.3°C, 3 timers:±0.1S
Flow-cell: 32ul quartz glass flow cell, 10mm
Display: 7’’ color LCD
Interface: RS-232 port
Input: Touching screen
Output: Internal thermal printer
Working Condition: Temperature 10°C-40°C, Humidity≤80%
Power Supply: AC 100V/220V±10%, 50-60Hz, 100VA
Dimension: 340*270*160mm (L*W*H)
Net Weight: 5Kg
