Features
Easy Windows operation software, with touch screen or mouse, Large LCD display
8-channel optical fiber system enables 5 secs’ reading for the whole plate
Bichromatic measurement, calculation modes including Absorbance, Cut-off, Curve, Linear regression,
Index regression, Logarithm regression, Exponential regression, Power regression, etc
Random positive control and negative control setting
Multi-assay feature enables up to 12 different assays on one plate
Large memory storage up to 100 programs, 1000 patients data, 10000 sample records
Powerful QC function: Immediate, Elisa including Westguard Rules, Levey Jennings plot(optional)
Ability to communicate with PC for data management (optional)
Easy software upgrade by SD card, support USB mouse and keyboard
Multiform result output including patient comprehensive report
With lamp sleeping and wake-up function
Plate shaking function
Auto self-check when power on
Technical Specification
Read-out Range: 0 – 3.500Abs
Resolution: 0.001Abs(displayed),0.0001Abs(calculated)
Accuracy: ±0.03Abs (0 – 2.000Abs)
Light Source: Halogen lamp
Wavelengths: 405, 450, 492, 630nm, 4 more filters optional
Wavelength Accuracy: ± 2.0nm
Band width: < 10nm
Calculation Method: ABS, Cut-off, Curve, Linear regression, Index regression,
Logarithm regression, Exponential regression, etc
Reading Speed: 5 seconds for 96 well plate (single wavelength)
Shaking Plate: Shaking time and speed adjustable
Memory: 100 programs, 1000 patients data, 10000 sample records
Interface: RS-232, USB, SD card interface
Display: 6” large LCD
Input: Touch screen, mouse or external keyboard
Output: External printer (optional)
Power Supply: AC 110V-220V ± 10%, 50-60Hz
Working Conditions: Temperature: 10°C ~35°C , Humidity: 15%~85%
Net weight: 8Kg
Dimension: 460×330×190mm(L×W×H)
