Features
– Random access
– Up to 30 samples can be scanned simultaneously
– Throughput up to 60 samples /hour
– Temperature compensation refer to 18oC according to Westergren method
– ESR curve display and print-out
– Touch screen , large LCD display
– Internal thermal printer
– Operation system support multiple languages (English, Spanish, French, Italian)
Technical Specification
Application area Erythrocyte sedimentation rate analysis
Measuring principle Infrared sensor
Reading channels 30 available channels
Loading capability Up to 30 samples at a time
Loading pattern Random
Measuring time 30 minutes or 60 minutes selectable
Throughput Up to 60 samples per hour
Analysis result In Westergren ESR value (mm/hr)
Temperature compensation Refer to 18°C automatically (selectable)
Reading resolution 0.2mm
Reproducibility < 0.3% or 2mm/1h
Result resolution 1mm/1h
Blood level range 50mm~64mm
Display LCD
Input Touch screen
Interface RS-232 serial port
Print Internal thermal printer
Power supply AC 220V/110V ±10%, 50/60/Hz, 50W
Operation conditions 15C°~32°C Humidity ≤85%
Dimension 400mm×300mm×200mm(L×W×H)
Net weight 11.5kg
